Imported No Order No. BX-A2B Customized processing No

Item No. BX-A2B Brand BOOXT Model BX-A2B

Chisel shape round Chisel diameter 20 (mm) Piston diameter 28.5 (mm)

Stroke of the hammer body 75 (mm) Air consumption 13 (L/s) Air intake pipe size 3/8

Working pressure 0.65 (Mpa) Hammer weight 7.3 (kg) Scope of application Casting stripping; cement removal; mining of mineral deposits; culvert rock crushing and other operations

Outer size 397 (mm) Machine weight 7.3 (kg) Working pressure 0.65Mpa

Average air consumption 0.7 cubic meters/minute Tool length 397 Hammer net weight 7.3 (kg)

Whether it is a special supply source for cross-border export? No Series Air Pick The number of blows 2300bpm
