Imported No Order No. BX-500E Customized processing No

Item No. BX-500E Brand BOOXT Model BX-500E

The maximum pull stud size 4.8 (mm) The size of the self-contained gun head 23 (mm) Tension 1060 (kg)

Pull stud stroke 18 (mm) Air inlet size 1/4 (inch) Recommended inner diameter of trachea 8 (mm)

Working pressure 0.65 (Mpa) Average air consumption 0.13m3/min Height 291 (mm)

Tool height 291 (mm) Total length 195 (mm) Scope of application The national standard 2.4/3.2/4.0/4.8 various materials of blind rivets.

Net weight of the tool 1.3 (kg) Is it a source of exclusive supply for cross-border expor
