Imported No Order No. BX-602 Customized processing No

Item No. BX-602 Brand BOOXT Model BX-602

Maximum pull stud size M6-M8 (mm) Self-contained gun head size M6-M8 (mm) Pull force 790 (kg)

Pull stud stroke 6 (mm) Air inlet size 1/4 (inch) Recommended inner diameter of trachea 8 (mm)

Working pressure 0.65 (Mpa) Average air consumption 0.61m3/min Height 170 (mm)

Tool height 170 (mm) Total length 202 (mm) Scope of application Suitable for industrial riveting operations such as hardware and plastic products.

Tool length 202mm Tool net weight 1.14 (kg) Is it a source of exclusive supply for cross-border export
