Imported No Order No. LG-804 Customized processing No
Item No. LG-804 Brand BOOXT Model LG-804
Maximum pull stud size M8-M10 (mm) Self-contained gun head size M8-M10 (mm) Pull force 1900 (kg)
Pull stud stroke 5 (mm) Air inlet size 1/4 (inch) Recommended inner diameter of trachea 8 (mm)
Working pressure 0.65 (Mpa) Average air consumption 0.55m3/min Height 170 (mm)
Tool height 170 (mm) Total length 235 (mm) Applicable scope Industrial riveting operations such as hardware and plastic products
Tool length 235mm Tool net weight 1.2 (kg) Is it a source of exclusive supply for cross-border export?
